Features:

Safety contacts are used to detect the danger of moving parts squeezing or shearing people. It is a close proximity safety protection device for automatic equipment that meets safety protection requirements and is used to ensure the safety of personnel in hazardous areas who may face dangerous situations such as pinching, squeezing, and collision.

◆ High triggering sensitivity；
◆ Small size for easy concealed installation；
◆ The appearance and installation method can be configured arbitrarily. According to user requirements, the safety contact can be made into an arc shape or other shapes；
◆ Suitable for various industrial occasions, according to requirements, we can provide products with special requirements such as oil resistance, acid and alkali resistance.
Contact parameters：

detection	Pressure sensing method
Maximum sensing angle	<90o
Trigger Force	≥25N
mechanical life	>3×106 次
Material of surface protection layer	EPDM
operation temperature	-20℃~+55℃
protection grade	IP65
ambient humidity	95% (23℃) No condensation?

controller parameters：

model	SM3P2A1B24
INPUT VOLTAGE?	24V DC
security level	PL d
voltage tolerance	±10%
operation temperature	-10~+55℃
storage temperature	-40~+85℃
consumption	<3W
protection grade	IP50
Output	2NO+1NC
Maximum switching capacity?	AC-15,5A/250? DC-13,6A/24V
Anti interference level	IEC61131-3
Contact fuse protection	5AT or 6AF
Voltage withstand level	AC 1890V 50/60Hz 1min
response time	<30ms
Wire cross-sectional area	0.2 - 2.5mm2
Standards	EN ISO 13849-1, EN1760-2?EN 61000-6-2, EN 61000-6-3
Torque setting of the terminal	0.5Nm
size	96(L)×22.5(W)×116(H)mm
Vibration requirements	EN 60068-2-6?
Environmental compliance	EN 60068-2-78
